brass GAS valve
Features
- Swing Type
- Screwed female ends to IS 554 / BS 21 / ISO 7
- Permits flow in one direction and shuts automatically if flow reverses
- Forged brass body construction
Test Pressure (Hydrostatic)
- Shell: 25 kg/cm²g (350 psig)
- Seat: 16 kg/cm²g (225 psig)
- Maximum Working Temperature: 220°C
- Suitable For: Water, Oil, Air
Material Specification
| Part No. | Name of Part | Material | Qty |
|---|---|---|---|
| 1 | Nozel | Brass CW 614N | 1 |
| 2 | Body | Brass CW 614N | 1 |
| 3 | Ball | Brass CW 614N | 1 |
| 4 | Seal Ring | PTFE | 2 |
| 5 | Handle | Aluminium Alloy | 1 |
| 6 | Handle Nut | MS | 1 |
Sizes / Dimensions
Size:¼” (15mm), ⅜” (20mm), ½” (25mm)
