brass spring check valve

Features

• Multi-utility non-return valve
• Manufactured from brass material CW 617N
• Pressure Rating:
  • PN 25 Bar (½", ¾" & 1")
  • PN 18 Bar (1¼", 1½" & 2")
• BSP female thread pipe connection

Test Pressure (Hydrostatic)

• Shell: 25 kg/cm²g (350 psig)
• Seat: 16 kg/cm²g (225 psig)
• Maximum Working Temperature: 220°C
• Suitable For: Water, Oil, Air

Sizes / Dimensions

Size: ½” (15mm), ¾” (20mm), 1” (25mm), 1¼” (32mm), 1½” (40mm), 2” (50mm)
